| Nominal Size: | 35" x 6" |
| Cylinders: |
6-1/2" Cutting Circle Bits per Head 5 Rows of Bits (290 per Machine) |
| Drive: | Vee-Belt |
| Motors: |
Upper Cutterhead - 50 hp std. or 60 hp Optional Lower Cutterhead - 40 hp std. or 50 hp Optional Feed - 5hp Variable Speed Platen Elevation - 2 hp Grinder Motor - 1/10 hp |
| Center to Center Distance Between Cutterheads: | 61" |
| Voltages: | 208-575, 3-phase, 50-60 Hz (230/460 or 575 standard) |
| Lower Feed Rolls: | 2 5-1/8"" Solid Steel, Power Driven Sealed Bearings |
| Lower Idler Rollers: | 2 4" Diameter Non-powered |
| Upper Feed Rolls: |
Infeed - 5-1/8" Diameter 2" Ductile Sections Spring Loaded |
| Outfeed: | 5-1/8" Solid Steel Power Driven Steel Bearings |
| Feed Speed: | 25 to 100 Lineal Feet per Minute (Higher or Lower Available in Same Ratio) |
| Chipbreaker: | 2" Sections, Concentric with Head |
| Maximum Stock Width: | 35-3/8" |
| Shortest Butted Piece: | 8" |
| Shortest Single Piece: | 15" |
| Maximum Stock Thickness: | 6" |
| Minimum Stock Thickness: | 1/4" |
| Maximum Depth of Cut: | 1/2" |
| Carpet Feed Conveyor: | 2070 pins |
| Upper Dusthood: | 10" Diameter Outlet |
| Lower Dusthood: | 8" Diameter Outlet |
| Floor Space: | 127"W x 124"L x 77"H (Note: This is the size of the machine with a grinding arm extended) |
| Net Weight: | 20,000 lbs. |
| Domestic Shipping Weight: | 22,000 lbs. |
